RotoFlex

Classification
18 12 10 38 - Beds with ingress and egress function



The product series contains 2 products.

Product 1 of 2
RotoCare


HMI-no.
70877
Article-no.
920

Registration date
23-02-2012
Last updated
17-12-2019

Specifications
Intended for children No  info
Products for children must comply with the specific demands for safety as stated in certain standards. It is the supplier of the product who has stated that the product is intended for children. The National Board of Social Services holds no responsibility in relation to this assessment.
Outside measure length 220 cm
Outside measure width 93 cm
Mattress size, length 213 cm
Mattress size, width 88 cm
Load, max 200 kg info
Maximum external load on the product that is permitted in normal use
User weight, max 175 kg
Weight of heaviest main part 60 kg info
Weight without parts that are detachable without the use of tools
Ingress protection class for water 4 IP-klasse info
0-9 (IPX0-IPX9) according to the standard for degrees of protection provided by enclosures (IEC 60529)
Built-in bed extension Yes
Intended for use in hospitals No
Intended for use in a domestic area Yes
Mattress support platform, height above floor, min 40 cm info
Measured without mattress
Mattress support platform, height above floor, max 80 cm info
Measured without mattress
Number of sections of mattress support platform, transversely 4
Under bed clearance 15 cm info
Minimum under bed clearance in the 100 cm middle area measured from the floor with the mattress support platform 40 cm above the floor or - if the bed cannot achieve this position - then measured in the lowest position of the mattress support platform
Central braking system Yes
Wheel diameter 10 cm
Back rest section, electrical adjustment Yes
Leg section, electrical adjustment Yes
Upper leg section, electrical adjustment Yes
Height adjustment, electrical Yes
Separate adjustment of back rest Yes  info
Indicates whether the back rest can be adjusted independently of other parts of the mattress support platform
Combined adjustment of mattress support platform No  info
Indicates whether back rest and knee bending are adjusted at the same time
Egress from the side of the bed Yes  info
E.g. by way of rotation of the mattress support platform
Egress via the foot end No
Electrically operated egress function No
Removable bed-rails Yes
Removable self-lifting rail Yes
Removable foot board Yes
Removable head board Yes
Heigh cot sides Yes  info
Intended to prevent a person (usually a child) in getting out of the bed.
Adjustable head support section No
Trendelenburg, manual operation No
Trendelenburg, electrical operation No
Anti-trendelenburg, manual operation No
Anti-trendelenburg, electrical operation No



Product 2 of 2
RotoFlex


HMI-no.
48833
Article-no.
910

Registration date
15-05-2008
Last updated
17-12-2019

Specifications
Intended for children No  info
Products for children must comply with the specific demands for safety as stated in certain standards. It is the supplier of the product who has stated that the product is intended for children. The National Board of Social Services holds no responsibility in relation to this assessment.
Outside measure length 220 cm
Outside measure width 93 cm
Mattress size, length 213 cm
Mattress size, width 88 cm
Load, max 200 kg info
Maximum external load on the product that is permitted in normal use
User weight, max 170 kg
Weight of heaviest main part 60 kg info
Weight without parts that are detachable without the use of tools
Ingress protection class for water 4 IP-klasse info
0-9 (IPX0-IPX9) according to the standard for degrees of protection provided by enclosures (IEC 60529)
Built-in bed extension Yes
Intended for use in hospitals No
Intended for use in a domestic area Yes
Mattress support platform, height above floor, min 40 cm info
Measured without mattress
Mattress support platform, height above floor, max 80 cm info
Measured without mattress
Number of sections of mattress support platform, transversely 4
Under bed clearance 15 cm info
Minimum under bed clearance in the 100 cm middle area measured from the floor with the mattress support platform 40 cm above the floor or - if the bed cannot achieve this position - then measured in the lowest position of the mattress support platform
Central braking system Yes
Wheel diameter 10 cm
Back rest section, electrical adjustment Yes
Leg section, electrical adjustment Yes
Upper leg section, electrical adjustment Yes
Height adjustment, electrical Yes
Separate adjustment of back rest Yes  info
Indicates whether the back rest can be adjusted independently of other parts of the mattress support platform
Combined adjustment of mattress support platform Yes  info
Indicates whether back rest and knee bending are adjusted at the same time
Egress from the side of the bed Yes  info
E.g. by way of rotation of the mattress support platform
Egress via the foot end No
Electrically operated egress function Yes
Removable bed-rails Yes
Removable self-lifting rail Yes
Removable foot board Yes
Removable head board Yes
Heigh cot sides Yes  info
Intended to prevent a person (usually a child) in getting out of the bed.
Adjustable head support section Yes
Trendelenburg, manual operation No
Trendelenburg, electrical operation No
Anti-trendelenburg, manual operation No
Anti-trendelenburg, electrical operation No
