The product series contains 12 products.

Specifications summarized

Specifications for the 12 products in the product series. Click a HMI-no. to see all details for a single product.

Product 1 - 10
Specification/HMI-no.	104892	106162	106165	106168	104896	106163	106166	106169	106161	106164
Height adjustable	Manuelt	Manuelt	Hydraulik/ gas	Hydraulik/ gas	Manuelt	Manuelt	Hydraulik/ gas	Hydraulik/ gas	Manuelt	Manuelt
Tension adjustable back rest upholstery	No	No	No	No	No	No	No	No	No	No
Can be used with standard wall-mounted toilets (without extension)	No	Yes	Yes	Yes	No	Yes	Yes	Yes	No	Yes
Possibility to change position of armrest to allow sideways transfer	No	No	No	No	No	No	No	No	No	No
Head support	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Fold-up foot supports	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Height adjustable legrests	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Elevating legrests	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes
Legrest position may be changed to facililtate hygiene and transfer	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes
User weight, max (kg)	150	150	100	100	150	150	100	100	150	150
Total width (cm)	54	54	54	54	58	54	54	54	59	54
Ground clearance (cm) Measured from the floor to the lowest point under the seat. Measured without bedpan/collection receptacle.	51	51	66	66	51	51	66	66	51	51
Width between arm supports (cm) Smallest distance measured between the inside of the arm supports. If the arm supports are adjustable, this is measured with the arm supports in the widest position.	42	42	42	42	48	48	48	48	54	54
Seat depth (cm) If the seat depth is adjustable, this is the maximum seat depth	38	38	38	38	47	47	47	47	55	55
Seat height, min (cm)	52	53	53	53	52	53	53	53	53	53
Seat height, max (cm)	62	63	63	63	62	78	78	78	78	78
Tilt-in-space forward (°) Measured from the horizontal position.	5	5	5	5	5	5	5	5	5	5
Tilt-in-space back (°) Measured from the horizontal position.	30	30	30	30	30	30	30	30	30	30
Number of wheels with brake	4	4	4	4	4	4	4	4	4	4
Wheel diameter (mm)	100	100	100	100	100	100	100	100	100	100
Height of push handles/push bar, min. (cm) Measured from the floor to the upper surface of the grip. According to ISO 17966:2016 it shall be possible to push the chair with the grip 90 cm above the floor.	90	90	90	90	92	92	92	92	94	94
Height of push handles/push bar, max. (cm) Measured from the floor to the upper surface of the heigher grip with the chair in the highest position	120	120	120	120	130	130	130	130	140	140

Product 11 - 12
Specification/HMI-no.	106167	106170
Height adjustable	Hydraulik/ gas	Hydraulik/ gas
Tension adjustable back rest upholstery	No	No
Can be used with standard wall-mounted toilets (without extension)	Yes	Yes
Possibility to change position of armrest to allow sideways transfer	No	No
Head support	Yes	Yes
Fold-up foot supports	Yes	Yes
Height adjustable legrests	Yes	Yes
Elevating legrests	Yes	Yes
Legrest position may be changed to facililtate hygiene and transfer	Yes	Yes
User weight, max (kg)	120	120
Total width (cm)	59	59
Ground clearance (cm) Measured from the floor to the lowest point under the seat. Measured without bedpan/collection receptacle.	66	66
Width between arm supports (cm) Smallest distance measured between the inside of the arm supports. If the arm supports are adjustable, this is measured with the arm supports in the widest position.	54	54
Seat depth (cm) If the seat depth is adjustable, this is the maximum seat depth	55	55
Seat height, min (cm)	53	53
Seat height, max (cm)	78	78
Tilt-in-space forward (°) Measured from the horizontal position.	5	5
Tilt-in-space back (°) Measured from the horizontal position.	30	30
Number of wheels with brake	4	4
Wheel diameter (mm)	100	100
Height of push handles/push bar, min. (cm) Measured from the floor to the upper surface of the grip. According to ISO 17966:2016 it shall be possible to push the chair with the grip 90 cm above the floor.	94	94
Height of push handles/push bar, max. (cm) Measured from the floor to the upper surface of the heigher grip with the chair in the highest position	140	140
