TSN HS-268




Classification
12 23 03 05 - Powered wheelchair, manual steering, class A (primarily for indoor use)



The product series contains 2 products.

Specifications summarized

Specifications for the 2 products in the product series. Click a HMI-no. to see all details for a single product.

Product 1 - 2
Specification/HMI-no.136636136599
Number of wheels44
ProgrammableNoNo
SuspensionNoNo
Can be used as seat in a carNoNo
Can be disassembled without toolsYesYes
With cubicle NoNo
User weight, max (kg)115115
Width (cm)
Maximum external width.
51.251.2
Length (cm)
Maximum external length without extra accessories.
95.395.3
Weight (kg)29.930.8
Seat height, min (cm)
The vertical distance between the foot rest and the seat surface measured at the front edge of the seat. Measured with the seat in the lowest position.
6060
Seat height, max (cm)
The vertical distance between the foot rest and the seat surface measured at the front edge of the seat. Measured with the seat in the highest position.
6767
Speed, max (km/t)88
Driving distance range, fully charged (km)
The theoretical driving distance range as calculated through laboratory testing.
1515
Ground clearance (cm)4.34.3
Slope, max (°)66
Climbs obstacles of max (cm)55
Weight of heaviest main part (kg)2.82.8
