Apollo 539



Compact, high-quality 3-wheel mobility scooter with a low step-through design and comfortable swivel seat. Ideal for users under 175 cm and suitable for both indoor and outdoor use. Easy to dismantle for car transport. Equipped with LED lights, turn signals, mirrors, horn and battery indicator.

Classification
12 23 03 06 - Powered wheelchair, manual steering, class B (for indoor and outdoor use)

Documents
User manual

Video
Play video


The product series contains 1 product.

Apollo 539


HMI-no.
50207
Article-no.
HS 539

Registration date
11-11-2008
Last updated
07-09-2026

Properties
Number of wheels
3
Programmable
Yes
Suspension
Yes
Can be used as seat in a car
No
With cubicle
No

Measures
User weight, max
120
kg
Width
62.5
cm
Maximum external width.
Length
120
cm
Maximum external length without extra accessories.
Weight
76.7
kg
Seat height, min
62.5
cm
The vertical distance between the foot rest and the seat surface measured at the front edge of the seat. Measured with the seat in the lowest position.
Seat height, max
67.5
cm
The vertical distance between the foot rest and the seat surface measured at the front edge of the seat. Measured with the seat in the highest position.
Speed, max
12
km/t
Driving distance range, fully charged
40
km
The theoretical driving distance range as calculated through laboratory testing.
Ground clearance
10.5
cm
Slope, max
12
°
Climbs obstacles of max
5
cm

Test information
No information about tests according to standards
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

EU product safety regulation
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device
EU declaration of conformity for HMI-no. 50207
