Bariatric Wheelchair Minimaxx




Classification
12 22 03 11 - Manual wheelchairs, sideways foldable, standard measures

Documents
Brochure
User manual


The product series contains 4 products.

» Summarize specifications

Product 1 of 4
Minimaxx Bariatric Wheelchair sw 56 cm


HMI-no.
54891
Article-no.
0100-056-000

Registration date
12-03-2010
Last updated
07-11-2025

Properties
Adjustable seat angle
No
Balance point adjustable
Yes
Available with hard base
Yes
As opposed to sling seat
Back rest angle adjustable
No
Height adjustable back rest
No
Push handles
Yes
Front-wheel-driven
No
Intended for fastening in a car
No
Adjustable seat depth
No
The seat depth in this specific frame can be altered by adjustment or replacement of component(s)

Measures
User weight, max
325
kg
Seat height, min
43
cm
Seat height, max
43
cm
Back rest height, min
51
cm
Back rest height, max
51
cm
Total width
89
cm
Total length
70
cm
Weight
27
kg
The weight of the wheelchair incl. wheels and leg supports.
Seat width
56
cm
Seat depth, min
46
cm
Possibly by adjustment
Seat depth, max
46
cm
Longest possible for this frame. Possibly identical to seat depth, min.

Test information
Though the product is testet, it might not have passed all requirements in the standard. Besides, some products are only tested according to parts of the standard. Read the test report for detailed information. See also other standards that could be relevant for this product type.
: Tested according to other national or international standard.
Test lab: SGS. Test date: 26-10-2009 Test report for HMI-no. 54891

EU product safety regulation
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device

Product 2 of 4
Minimaxx Bariatric Wheelchair sw 66 cm


HMI-no.
54788
Article-no.
0100-066-000

Registration date
03-03-2010
Last updated
07-11-2025

Properties
Adjustable seat angle
No
Balance point adjustable
Yes
Available with hard base
Yes
As opposed to sling seat
Back rest angle adjustable
No
Height adjustable back rest
No
Push handles
Yes
Front-wheel-driven
No
Intended for fastening in a car
No
Adjustable seat depth
No
The seat depth in this specific frame can be altered by adjustment or replacement of component(s)

Measures
User weight, max
325
kg
Seat height, min
43
cm
Seat height, max
43
cm
Back rest height, min
51
cm
Back rest height, max
51
cm
Total width
89
cm
Total length
70
cm
Weight
27
kg
The weight of the wheelchair incl. wheels and leg supports.
Seat width
66
cm
Seat depth, min
46
cm
Possibly by adjustment
Seat depth, max
46
cm
Longest possible for this frame. Possibly identical to seat depth, min.

Test information
Though the product is testet, it might not have passed all requirements in the standard. Besides, some products are only tested according to parts of the standard. Read the test report for detailed information. See also other standards that could be relevant for this product type.
: Tested according to other national or international standard.
Test lab: SGS. Test date: 26-10-2009 Test report for HMI-no. 54788

EU product safety regulation
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device

Product 3 of 4
Minimaxx Bariatric Wheelchair sw 71cm


HMI-no.
54789
Article-no.
0100-071-000

Registration date
03-03-2010
Last updated
07-11-2025

Properties
Adjustable seat angle
No
Balance point adjustable
Yes
Available with hard base
Yes
As opposed to sling seat
Back rest angle adjustable
No
Height adjustable back rest
No
Push handles
Yes
Front-wheel-driven
No
Intended for fastening in a car
No
Adjustable seat depth
No
The seat depth in this specific frame can be altered by adjustment or replacement of component(s)

Measures
User weight, max
325
kg
Seat height, min
43
cm
Seat height, max
43
cm
Back rest height, min
51
cm
Back rest height, max
51
cm
Total width
89
cm
Total length
70
cm
Weight
27
kg
The weight of the wheelchair incl. wheels and leg supports.
Seat width
71
cm
Seat depth, min
46
cm
Possibly by adjustment
Seat depth, max
46
cm
Longest possible for this frame. Possibly identical to seat depth, min.

Test information
Though the product is testet, it might not have passed all requirements in the standard. Besides, some products are only tested according to parts of the standard. Read the test report for detailed information. See also other standards that could be relevant for this product type.
: Tested according to other national or international standard.
Test lab: SGS. Test date: 26-10-2009 Test report for HMI-no. 54789

EU product safety regulation
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device

Product 4 of 4
Minimaxx Bariatric Wheelchair, sw 61cm


HMI-no.
53978
Article-no.
0100-061-000

Registration date
17-12-2009
Last updated
07-11-2025

Properties
Adjustable seat angle
No
Balance point adjustable
Yes
Available with hard base
Yes
As opposed to sling seat
Back rest angle adjustable
No
Height adjustable back rest
No
Push handles
Yes
Front-wheel-driven
No
Intended for fastening in a car
No
Adjustable seat depth
No
The seat depth in this specific frame can be altered by adjustment or replacement of component(s)

Measures
User weight, max
325
kg
Seat height, min
43
cm
Seat height, max
43
cm
Back rest height, min
51
cm
Back rest height, max
51
cm
Total width
89
cm
Total length
70
cm
Weight
27
kg
The weight of the wheelchair incl. wheels and leg supports.
Seat width
61
cm
Seat depth, min
46
cm
Possibly by adjustment
Seat depth, max
46
cm
Longest possible for this frame. Possibly identical to seat depth, min.

Test information
Though the product is testet, it might not have passed all requirements in the standard. Besides, some products are only tested according to parts of the standard. Read the test report for detailed information. See also other standards that could be relevant for this product type.
: Tested according to other national or international standard.
Test lab: SGS. Test date: 26-10-2009 Test report for HMI-no. 53978

EU product safety regulation
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device
