Rea Spirea4NG Heavy Duty




Classification
12 22 03 11 - Manual wheelchairs, sideways foldable, standard measures

Documents
Brochure
User manual
QuickGuide
Accessories catalogue
Service manual


The product series contains 4 products.

» Summarize specifications

Product 1 of 4
Rea Spirea 4 NG Heavy Duty SW 55,5/SD 40


HMI-no.
70401
Article-no.
konfigurerbar

Registration date
13-01-2012
Last updated
22-10-2025

Properties
Adjustable seat angle
Yes
Balance point adjustable
Yes
Available with hard base
No
As opposed to sling seat
Back rest angle adjustable
No
Height adjustable back rest
Yes
Push handles
Yes
Front-wheel-driven
No
Intended for fastening in a car
Yes

Measures
User weight, max
160
kg
Seat height, min
46
cm
Seat height, max
51
cm
Back rest height, min
38
cm
Back rest height, max
46
cm
Total width
75.5
cm
Total length
69
cm
Weight
16
kg
The weight of the wheelchair incl. wheels and leg supports.
Seat width
55.5
cm
Seat depth, min
40
cm
Possibly by adjustment

Test information
No information about tests according to standards
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

EU product safety regulation
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device

Product 2 of 4
Rea Spirea 4 NG Heavy Duty SW 60,5/SD 50


HMI-no.
70402
Article-no.
konfigurerbar

Registration date
13-01-2012
Last updated
22-10-2025

Properties
Adjustable seat angle
Yes
Balance point adjustable
Yes
Available with hard base
No
As opposed to sling seat
Back rest angle adjustable
No
Height adjustable back rest
Yes
Push handles
Yes
Front-wheel-driven
No
Intended for fastening in a car
Yes

Measures
User weight, max
160
kg
Seat height, min
46
cm
Seat height, max
51
cm
Back rest height, min
38
cm
Back rest height, max
46
cm
Total width
80.5
cm
Total length
69
cm
Weight
16
kg
The weight of the wheelchair incl. wheels and leg supports.
Seat width
60.5
cm
Seat depth, min
45
cm
Possibly by adjustment

Test information
No information about tests according to standards
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

EU product safety regulation
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device

Product 3 of 4
Rea Spirea4NG Heavy Duty SB 60,5/SD 40-45


HMI-no.
106727
Article-no.
konfigurerbar

Registration date
11-10-2017
Last updated
22-10-2025

Properties
Adjustable seat angle
Yes
Balance point adjustable
Yes
Available with hard base
No
As opposed to sling seat
Back rest angle adjustable
No
Height adjustable back rest
Yes
Push handles
Yes
Front-wheel-driven
No
Intended for fastening in a car
Yes
Adjustable seat depth
Yes
The seat depth in this specific frame can be altered by adjustment or replacement of component(s)

Measures
User weight, max
160
kg
Seat height, min
46
cm
Seat height, max
51
cm
Back rest height, min
38
cm
Back rest height, max
46
cm
Total width
80.5
cm
Total length
69
cm
Weight
16
kg
The weight of the wheelchair incl. wheels and leg supports.
Seat width
60.5
cm
Seat depth, min
40
cm
Possibly by adjustment
Seat depth, max
45
cm
Longest possible for this frame. Possibly identical to seat depth, min.

Test information
No information about tests according to standards
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

EU product safety regulation
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device

Product 4 of 4
Rea Spirea4NG Heavy Duty SW 55,5/SD 45


HMI-no.
144394
Article-no.
Konfigurerbar

Registration date
02-05-2025
Last updated
22-10-2025

Properties
Adjustable seat angle
Yes
Balance point adjustable
Yes
Available with hard base
No
As opposed to sling seat
Back rest angle adjustable
No
Height adjustable back rest
Yes
Push handles
Yes
Front-wheel-driven
No
Intended for fastening in a car
Yes

Measures
User weight, max
160
kg
Seat height, min
46
cm
Seat height, max
51
cm
Back rest height, min
38
cm
Back rest height, max
46
cm
Total width
75.5
cm
Total length
69
cm
Weight
16
kg
The weight of the wheelchair incl. wheels and leg supports.
Seat width
55.5
cm
Seat depth, min
45
cm
Possibly by adjustment

Test information
No information about tests according to standards
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

EU product safety regulation
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device
EU declaration of conformity for HMI-no. 144394
