Doorstep ramps


Classification
18 24 12 04 - Threshold ramps, double-sided




The product series contains 1 product.

Product 1 of 1
Doorstep ramps


HMI-no.
83815
Article-no.
MBX-DS4025

Registration date
27-10-2015
Last updated
21-11-2023

Properties
Outdoor use
Yes
Indoor use
Yes

Measures
Length in direction of travel
40
cm
Width
25
cm
Threshold height, min
30
mm
info
The minimal height of threshold that the ramp can be used with
Threshold height, max
70
mm
info
The maximum height of threshold that the ramp is intended for
Weight
2.16
kg
Load, max
350
kg

Test information info
Though the product is testet, it might not have passed all requirements in the standard. Besides, some products are only tested according to parts of the standard. Read the test report for detailed information. See also other standards that could be relevant for this product type.
EN 12182:2012: Assistive products for persons with disability - General requirements and test methods.
Test lab: Warszawa, Polen . Test date: 12-01-2016 Test report for HMI-no. 83815

EU product safety regulation info
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device
