Quickramps



Quickramps - improve everyday life. Without PVC or other toxic materials
From 4 mm till 60 mm.

Classification
18 24 12 03 - Threshold ramps, single-sided

Documents


The product series contains 19 products.

Product 1 of 19
Quickramp 10 mm


HMI-no.
Article-no.
QUICKRAMP 006C

Registration date
24-02-2016
Last updated
14-03-2022

Properties
Outdoor use
Yes
Indoor use
Yes

Measures
Length in direction of travel
10
cm
Width
100
cm
Threshold height, min
10
mm
info
The minimal height of threshold that the ramp is intended for
Threshold height, max
10
mm
info
The maximum height of threshold that the ramp is intended for
Weight
0.405
kg
Load, max
500
kg

Test information
No information about tests according to standards info
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

CE-marking info
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
Medical Device Regulation (MDR) - 2017/745/EU


Product 2 of 19
Quickramp 12 mm


HMI-no.
Article-no.
QUICKRAMP 012C

Registration date
07-03-2016
Last updated
14-03-2022

Properties
Outdoor use
Yes
Indoor use
Yes

Measures
Length in direction of travel
12.5
cm
Width
100
cm
Threshold height, min
12
mm
info
The minimal height of threshold that the ramp is intended for
Threshold height, max
12
mm
info
The maximum height of threshold that the ramp is intended for
Weight
0.405
kg
Load, max
2000
kg

Test information
No information about tests according to standards info
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

CE-marking info
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
Medical Device Regulation (MDR) - 2017/745/EU


Product 3 of 19
Quickramp 14 mm


HMI-no.
Article-no.
QUICKRAMP 014C

Registration date
08-03-2016
Last updated
14-03-2022

Properties
Outdoor use
Yes
Indoor use
Yes

Measures
Length in direction of travel
12.5
cm
Width
100
cm
Threshold height, min
14
mm
info
The minimal height of threshold that the ramp is intended for
Threshold height, max
14
mm
info
The maximum height of threshold that the ramp is intended for
Weight
0.652
kg
Load, max
2000
kg

Test information
No information about tests according to standards info
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

CE-marking info
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
Medical Device Regulation (MDR) - 2017/745/EU


Product 4 of 19
Quickramp 16 mm


HMI-no.
Article-no.
QUICKRAMP 016C

Registration date
08-03-2016
Last updated
14-03-2022

Properties
Outdoor use
Yes
Indoor use
Yes

Measures
Length in direction of travel
15
cm
Width
100
cm
Threshold height, min
16
mm
info
The minimal height of threshold that the ramp is intended for
Threshold height, max
16
mm
info
The maximum height of threshold that the ramp is intended for
Weight
0.875
kg
Load, max
2000
kg

Test information
No information about tests according to standards info
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

CE-marking info
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
Medical Device Regulation (MDR) - 2017/745/EU


Product 5 of 19
Quickramp 18 mm


HMI-no.
121061
Article-no.
QUICKRAMP 018H

Registration date
13-01-2020
Last updated
14-03-2022

Properties
Outdoor use
Yes
Indoor use
Yes

Measures
Length in direction of travel
15
cm
Width
100
cm
Threshold height, min
18
mm
info
The minimal height of threshold that the ramp is intended for
Threshold height, max
18
mm
info
The maximum height of threshold that the ramp is intended for
Weight
1
kg
Load, max
2000
kg

Test information
No information about tests according to standards info
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

CE-marking info
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
Medical Device Regulation (MDR) - 2017/745/EU


Product 6 of 19
Quickramp 20 mm


HMI-no.
108111
Article-no.
QUICKRAMP 020C

Registration date
24-01-2018
Last updated
14-03-2022

Properties
Outdoor use
Yes
Indoor use
Yes

Measures
Length in direction of travel
15
cm
Width
100
cm
Threshold height, min
20
mm
info
The minimal height of threshold that the ramp is intended for
Threshold height, max
20
mm
info
The maximum height of threshold that the ramp is intended for
Weight
1
kg
Load, max
2000
kg

Test information
No information about tests according to standards info
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

CE-marking info
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
Medical Device Regulation (MDR) - 2017/745/EU


Product 7 of 19
Quickramp 24 mm


HMI-no.
127810
Article-no.
QUICKRAMP 024H

Registration date
18-01-2021
Last updated
14-03-2022

Properties
Outdoor use
Yes
Indoor use
Yes

Measures
Length in direction of travel
15
cm
Width
100
cm
Threshold height, min
24
mm
info
The minimal height of threshold that the ramp is intended for
Threshold height, max
24
mm
info
The maximum height of threshold that the ramp is intended for
Weight
1
kg
Load, max
2000
kg

Test information
No information about tests according to standards info
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

CE-marking info
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
Medical Device Regulation (MDR) - 2017/745/EU


Product 8 of 19
Quickramp 28 mm


HMI-no.
127813
Article-no.
QUICKRAMP 028H

Registration date
18-01-2021
Last updated
14-03-2022

Properties
Outdoor use
Yes
Indoor use
Yes

Measures
Length in direction of travel
17.5
cm
Width
100
cm
Threshold height, min
28
mm
info
The minimal height of threshold that the ramp is intended for
Threshold height, max
28
mm
info
The maximum height of threshold that the ramp is intended for
Weight
1
kg
Load, max
2000
kg

Test information
No information about tests according to standards info
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

CE-marking info
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
Medical Device Regulation (MDR) - 2017/745/EU


Product 9 of 19
Quickramp 32 mm


HMI-no.
127816
Article-no.
QUICKRAMP 032H

Registration date
18-01-2021
Last updated
14-03-2022

Properties
Outdoor use
Yes
Indoor use
Yes

Measures
Length in direction of travel
20
cm
Width
100
cm
Threshold height, min
32
mm
info
The minimal height of threshold that the ramp is intended for
Threshold height, max
32
mm
info
The maximum height of threshold that the ramp is intended for
Weight
2
kg
Load, max
2000
kg

Test information
No information about tests according to standards info
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

CE-marking info
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
Medical Device Regulation (MDR) - 2017/745/EU


Product 10 of 19
Quickramp 36 mm


HMI-no.
127819
Article-no.
QUICKRAMP 036H

Registration date
18-01-2021
Last updated
14-03-2022

Properties
Outdoor use
Yes
Indoor use
Yes

Measures
Length in direction of travel
20
cm
Width
100
cm
Threshold height, min
36
mm
info
The minimal height of threshold that the ramp is intended for
Threshold height, max
36
mm
info
The maximum height of threshold that the ramp is intended for
Weight
2
kg
Load, max
2000
kg

Test information
No information about tests according to standards info
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

CE-marking info
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
Medical Device Regulation (MDR) - 2017/745/EU


Product 11 of 19
Quickramp 4 mm


HMI-no.
Article-no.
QUICKRAMP 004A

Registration date
08-03-2016
Last updated
14-03-2022

Properties
Outdoor use
Yes
Indoor use
Yes

Measures
Length in direction of travel
5
cm
Width
100
cm
Threshold height, min
4
mm
info
The minimal height of threshold that the ramp is intended for
Threshold height, max
4
mm
info
The maximum height of threshold that the ramp is intended for
Weight
0.126
kg
Load, max
2000
kg

Test information
No information about tests according to standards info
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

CE-marking info
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
Medical Device Regulation (MDR) - 2017/745/EU


Product 12 of 19
Quickramp 40 mm


HMI-no.
127822
Article-no.
QUICKRAMP 040H

Registration date
18-01-2021
Last updated
14-03-2022

Properties
Outdoor use
Yes
Indoor use
Yes

Measures
Length in direction of travel
25
cm
Width
100
cm
Threshold height, min
40
mm
info
The minimal height of threshold that the ramp is intended for
Threshold height, max
40
mm
info
The maximum height of threshold that the ramp is intended for
Weight
2
kg
Load, max
2000
kg

Test information
No information about tests according to standards info
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

CE-marking info
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
Medical Device Regulation (MDR) - 2017/745/EU


Product 13 of 19
Quickramp 44 mm


HMI-no.
127825
Article-no.
QUICKRAMP 044H

Registration date
18-01-2021
Last updated
14-03-2022

Properties
Outdoor use
Yes
Indoor use
Yes

Measures
Length in direction of travel
25
cm
Width
100
cm
Threshold height, min
44
mm
info
The minimal height of threshold that the ramp is intended for
Threshold height, max
44
mm
info
The maximum height of threshold that the ramp is intended for
Weight
2
kg
Load, max
2000
kg

Test information
No information about tests according to standards info
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

CE-marking info
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
Medical Device Regulation (MDR) - 2017/745/EU


Product 14 of 19
Quickramp 48 mm


HMI-no.
127828
Article-no.
QUICKRAMP 048H

Registration date
18-01-2021
Last updated
14-03-2022

Properties
Outdoor use
Yes
Indoor use
Yes

Measures
Length in direction of travel
25
cm
Width
100
cm
Threshold height, min
48
mm
info
The minimal height of threshold that the ramp is intended for
Threshold height, max
48
mm
info
The maximum height of threshold that the ramp is intended for
Weight
2
kg
Load, max
2000
kg

Test information
No information about tests according to standards info
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

CE-marking info
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
Medical Device Regulation (MDR) - 2017/745/EU


Product 15 of 19
Quickramp 52 mm


HMI-no.
127831
Article-no.
QUICKRAMP 052H

Registration date
18-01-2021
Last updated
14-03-2022

Properties
Outdoor use
Yes
Indoor use
Yes

Measures
Length in direction of travel
30
cm
Width
100
cm
Threshold height, min
52
mm
info
The minimal height of threshold that the ramp is intended for
Threshold height, max
52
mm
info
The maximum height of threshold that the ramp is intended for
Weight
2
kg
Load, max
2000
kg

Test information
No information about tests according to standards info
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

CE-marking info
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
Medical Device Regulation (MDR) - 2017/745/EU


Product 16 of 19
Quickramp 56 mm


HMI-no.
127834
Article-no.
QUICKRAMP 056H

Registration date
18-01-2021
Last updated
14-03-2022

Properties
Outdoor use
Yes
Indoor use
Yes

Measures
Length in direction of travel
32.5
cm
Width
100
cm
Threshold height, min
56
mm
info
The minimal height of threshold that the ramp is intended for
Threshold height, max
56
mm
info
The maximum height of threshold that the ramp is intended for
Weight
2
kg
Load, max
2000
kg

Test information
No information about tests according to standards info
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

CE-marking info
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
Medical Device Regulation (MDR) - 2017/745/EU


Product 17 of 19
Quickramp 6 mm


HMI-no.
Article-no.
QUICKRAMP 006C

Registration date
08-03-2016
Last updated
14-03-2022

Properties
Outdoor use
Yes
Indoor use
Yes

Measures
Length in direction of travel
5
cm
Width
100
cm
Threshold height, min
6
mm
info
The minimal height of threshold that the ramp is intended for
Threshold height, max
6
mm
info
The maximum height of threshold that the ramp is intended for
Weight
0.140
kg
Load, max
2000
kg

Test information
No information about tests according to standards info
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

CE-marking info
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
Medical Device Regulation (MDR) - 2017/745/EU


Product 18 of 19
Quickramp 60 mm


HMI-no.
127837
Article-no.
QUICKRAMP 060H

Registration date
18-01-2021
Last updated
14-03-2022

Properties
Outdoor use
Yes
Indoor use
Yes

Measures
Length in direction of travel
32.5
cm
Width
100
cm
Threshold height, min
60
mm
info
The minimal height of threshold that the ramp is intended for
Threshold height, max
60
mm
info
The maximum height of threshold that the ramp is intended for
Weight
2
kg
Load, max
2000
kg

Test information
No information about tests according to standards info
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

CE-marking info
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
Medical Device Regulation (MDR) - 2017/745/EU


Product 19 of 19
Quickramp 8 mm


HMI-no.
Article-no.
QUICKRAMP 008C

Registration date
08-03-2016
Last updated
14-03-2022

Properties
Outdoor use
Yes
Indoor use
Yes

Measures
Length in direction of travel
7.5
cm
Width
100
cm
Threshold height, min
8
mm
info
The minimal height of threshold that the ramp is intended for
Threshold height, max
8
mm
info
The maximum height of threshold that the ramp is intended for
Weight
0.27
kg
Load, max
2000
kg

Test information
No information about tests according to standards info
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

CE-marking info
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
Medical Device Regulation (MDR) - 2017/745/EU
