Manuel Gas Comfort Chairs, rear wheel drive



Manual Gas Comfort Chair, Rear wheel drive, with gas operated tilt and recline, Swingaway legrests. Wheels in size 12, 16, 20 and 24 inches with Flexel.

Classification
12 22 18 04 - Manual comfort push wheelchairs with tilt-in-space



The product series contains 4 products.

» Summarize specifications

Product 1 of 4
Manual Gas Wheelchair with gas operated tilt and recline - Baritric si


HMI-no.
102812
Article-no.
5WLH-MR-GMS-16DFn-8F1/30

Registration date
31-10-2016
Last updated
11-09-2025

Properties
Adjustable seat width
Yes
Adjustable seat depth
Yes
Height adjustable back rest
Yes
Front-wheel-driven
No
Can be subsequently equipped with propulsion unit
Yes
Can be mounted on a stair climber
Yes
Intended for fastening in a car
Yes
Can be supplied with electrically operated tilt-in-space
Yes
Can be supplied with electrically operated back-rest recline
Yes
Head support
Yes
Can be supplied with central legrest
Yes
Balance point adjustable
Yes
Adjustable push handles
Yes
Wheels with handrims
No
Transit wheels
Yes
Foldable
No

Measures
Seat width, min
52
cm
Seat width, max
60
cm
Seat depth, min
49
cm
Seat depth, max
56
cm
Seat height, min
41
cm
Seat height, max
59
cm
Back rest height, min.
40
cm
Back rest height, max
65
cm
Total width
60
cm
The narrowest possible configuration.
Total length
86
cm
Weight
43
kg
The stated weight of the wheelchair is incl. wheels and leg supports.
User weight, max
160
kg
Tilt-in-space forward
18
°
Measured from the horizontal position.
Tilt-in-space back
45
°
Measured from the horizontal position.
Back rest recline, max
165
°
Recline of back rest from an upright position.

Test information
No information about tests according to standards
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

EU product safety regulation
No information about CE-marking
The supplier has not provided any information about CE-marking of the product. Explain CE-marking

Other specifications
Manual Gas chair, Width: W52-W60, Depth: D49, High back, H60, Foldable push handle.


Product 2 of 4
Manual Wheelchair with gas operated tilt and recline - Adult size


HMI-no.
102814
Article-no.
5MMM-MR-GMS-16DFn-8F1/30

Registration date
01-11-2016
Last updated
11-09-2025

Properties
Adjustable seat width
Yes
Adjustable seat depth
Yes
Height adjustable back rest
Yes
Front-wheel-driven
No
Can be subsequently equipped with propulsion unit
Yes
Can be mounted on a stair climber
Yes
Intended for fastening in a car
Yes
Can be supplied with electrically operated tilt-in-space
Yes
Can be supplied with electrically operated back-rest recline
Yes
Head support
Yes
Can be supplied with central legrest
Yes
Balance point adjustable
Yes
Adjustable push handles
Yes
Wheels with handrims
No
Transit wheels
Yes
Foldable
No

Measures
Seat width, min
42
cm
Seat width, max
50
cm
Seat depth, min
44
cm
Seat depth, max
51
cm
Seat height, min
41
cm
Seat height, max
49
cm
Back rest height, min.
40
cm
Back rest height, max
65
cm
Total width
60
cm
The narrowest possible configuration.
Total length
86
cm
Weight
43
kg
The stated weight of the wheelchair is incl. wheels and leg supports.
User weight, max
160
kg
Tilt-in-space forward
18
°
Measured from the horizontal position.
Tilt-in-space back
45
°
Measured from the horizontal position.
Back rest recline, max
165
°
Recline of back rest from an upright position.

Test information
No information about tests according to standards
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

EU product safety regulation
No information about CE-marking
The supplier has not provided any information about CE-marking of the product. Explain CE-marking

Other specifications
Manual Gas chair, Width: W42-W50, Depth: D44, Medium back, H50, Foldable push handle.


Product 3 of 4
Manual Wheelchair with gas operated tilt and recline - Junior size


HMI-no.
102815
Article-no.
5NSL-MR-GMS-16DFn-8F1/30

Registration date
01-11-2016
Last updated
11-09-2025

Properties
Adjustable seat width
Yes
Adjustable seat depth
Yes
Height adjustable back rest
Yes
Front-wheel-driven
No
Can be subsequently equipped with propulsion unit
Yes
Can be mounted on a stair climber
Yes
Intended for fastening in a car
Yes
Can be supplied with electrically operated tilt-in-space
Yes
Can be supplied with electrically operated back-rest recline
Yes
Head support
Yes
Can be supplied with central legrest
Yes
Balance point adjustable
Yes
Adjustable push handles
Yes
Wheels with handrims
No
Transit wheels
Yes
Foldable
No

Measures
Seat width, min
32
cm
Seat width, max
40
cm
Seat depth, min
38
cm
Seat depth, max
45
cm
Seat height, min
41
cm
Seat height, max
59
cm
Back rest height, min.
40
cm
Back rest height, max
65
cm
Total width
60
cm
The narrowest possible configuration.
Total length
86
cm
Weight
43
kg
The stated weight of the wheelchair is incl. wheels and leg supports.
User weight, max
160
kg
Tilt-in-space forward
18
°
Measured from the horizontal position.
Tilt-in-space back
45
°
Measured from the horizontal position.
Back rest recline, max
165
°
Recline of back rest from an upright position.

Test information
No information about tests according to standards
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

EU product safety regulation
No information about CE-marking
The supplier has not provided any information about CE-marking of the product. Explain CE-marking

Other specifications
Manual Gas chair, Width: W32-W40, Depth: D38, Low back, H40, Foldable push handle.


Product 4 of 4
Manual Wheelchair with gas operated tilt and recline - Paediatric size


HMI-no.
102816
Article-no.
5NTL-MR-GMS-16DFn-8F1/30

Registration date
01-11-2016
Last updated
11-09-2025

Properties
Adjustable seat width
Yes
Adjustable seat depth
Yes
Height adjustable back rest
Yes
Front-wheel-driven
No
Can be subsequently equipped with propulsion unit
Yes
Can be mounted on a stair climber
Yes
Intended for fastening in a car
Yes
Can be supplied with electrically operated tilt-in-space
Yes
Can be supplied with electrically operated back-rest recline
Yes
Head support
Yes
Can be supplied with central legrest
Yes
Balance point adjustable
Yes
Adjustable push handles
Yes
Wheels with handrims
No
Transit wheels
Yes
Foldable
No

Measures
Seat width, min
32
cm
Seat width, max
40
cm
Seat depth, min
30
cm
Seat depth, max
38
cm
Seat height, min
41
cm
Seat height, max
59
cm
Back rest height, min.
40
cm
Back rest height, max
65
cm
Total width
60
cm
The narrowest possible configuration.
Total length
82
cm
Weight
43
kg
The stated weight of the wheelchair is incl. wheels and leg supports.
User weight, max
160
kg
Tilt-in-space forward
18
°
Measured from the horizontal position.
Tilt-in-space back
45
°
Measured from the horizontal position.
Back rest recline, max
165
°
Recline of back rest from an upright position.

Test information
No information about tests according to standards
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

EU product safety regulation
No information about CE-marking
The supplier has not provided any information about CE-marking of the product. Explain CE-marking

Other specifications
Manual Gas chair, Width: W32-W40, Depth: D30, Low back, H40, Foldable push handle.
