Arjo, Miranti
Classification
12 36 09 01 - Mobile hoists for transferring a person in lying position
The product series contains 4 products.
Product 1 of 4
Arjo, Miranti standard
HMI-no.
20351
Article-no.
CEB8201-01
Registration date
06-01-1998
Last updated
17-06-2024
Properties
Ingress protection class for water
IPX4
0-9 (IPX0-IPX9) according to the standard for degrees of protection provided by enclosures (IEC 60529)
Electrical lifting mechanism
Yes
Width adjustment of base
No
Electrical width adjustment of base
No
Parallel width adjustment of base
No
Foldable
Yes
Can be disassembled without tools
No
Integrated battery charger
No
Emergency lowering function
No
Measures
User weight, max
160
kg
Support platform height, min
47.5
cm
Support platform height, max
106.5
cm
Support platform length
197
cm
Support platform width
50.9
cm
Internal width of base, max
84
cm
External width, max
95
cm
Height of base at front
15
cm
Turning diameter
195
cm
Weight of heaviest main part
95
kg
Maintenance frequency
12
måneder
Test information
No information about tests according to standards ![info](/en/img/i.svg)
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type
EU product safety regulation ![info](/en/img/i.svg)
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device
Product 2 of 4
Arjo, Miranti standard with scale
HMI-no.
34187
Article-no.
CEB 8301-01
Registration date
13-03-2003
Last updated
17-06-2024
Properties
Ingress protection class for water
IPX4
0-9 (IPX0-IPX9) according to the standard for degrees of protection provided by enclosures (IEC 60529)
Electrical lifting mechanism
Yes
Width adjustment of base
No
Electrical width adjustment of base
No
Parallel width adjustment of base
No
Foldable
Yes
Can be disassembled without tools
No
Integrated battery charger
No
Emergency lowering function
No
Measures
User weight, max
160
kg
Support platform height, min
47.5
cm
Support platform height, max
106.5
cm
Support platform length
197
cm
Support platform width
50.9
cm
Internal width of base, max
84
cm
External width, max
95
cm
Height of base at front
15
cm
Turning diameter
195
cm
Weight of heaviest main part
103
kg
Maintenance frequency
12
måneder
Test information
No information about tests according to standards ![info](/en/img/i.svg)
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type
EU product safety regulation ![info](/en/img/i.svg)
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device
Product 3 of 4
Arjo, Miranti with Power Drive
HMI-no.
34186
Article-no.
CEB 8101-01
Registration date
13-03-2003
Last updated
17-06-2024
Properties
Ingress protection class for water
IPX4
0-9 (IPX0-IPX9) according to the standard for degrees of protection provided by enclosures (IEC 60529)
Electrical lifting mechanism
Yes
Width adjustment of base
No
Electrical width adjustment of base
No
Parallel width adjustment of base
No
Foldable
Yes
Can be disassembled without tools
No
Integrated battery charger
No
Emergency lowering function
No
Measures
User weight, max
160
kg
Support platform height, min
47.5
cm
Support platform height, max
106.5
cm
Support platform length
197
cm
Support platform width
50.9
cm
Internal width of base, max
84
cm
External width, max
95
cm
Height of base at front
15
cm
Turning diameter
195
cm
Weight of heaviest main part
103
kg
Maintenance frequency
12
måneder
Test information
No information about tests according to standards ![info](/en/img/i.svg)
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type
EU product safety regulation ![info](/en/img/i.svg)
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device
Product 4 of 4
Arjo, Miranti with Power Drive and scale
HMI-no.
34185
Article-no.
CEB 8001-01
Registration date
13-03-2003
Last updated
17-06-2024
Properties
Ingress protection class for water
IPX4
0-9 (IPX0-IPX9) according to the standard for degrees of protection provided by enclosures (IEC 60529)
Electrical lifting mechanism
Yes
Width adjustment of base
No
Electrical width adjustment of base
No
Parallel width adjustment of base
No
Foldable
Yes
Can be disassembled without tools
No
Integrated battery charger
No
Emergency lowering function
No
Measures
User weight, max
160
kg
Support platform height, min
47.5
cm
Support platform height, max
106.5
cm
Support platform length
197
cm
Support platform width
50.9
cm
Internal width of base, max
84
cm
External width, max
95
cm
Height of base at front
15
cm
Turning diameter
195
cm
Weight of heaviest main part
103
kg
Maintenance frequency
12
måneder
Test information
No information about tests according to standards ![info](/en/img/i.svg)
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type
EU product safety regulation ![info](/en/img/i.svg)
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device
