ErGo-Tilt 4000
Classification
09 12 03 11 - Commode shower chairs with wheels, tilt and electrical functions
Video
The product series contains 2 products.
Product 1 of 2
ErGo-Tilt 4000
HMI-no.
108696
Article-no.
TS-25000
Registration date
07-03-2018
Last updated
19-12-2023
Properties
Possibility to change position of armrest to allow sideways transfer
Ja, opklappelige
Properties
Height adjustable
Elektrisk
Properties
Number of wheels with brake
4
Properties
Ingress protection class for water
IPX6
0-9 (IPX0-IPX9) according to the standard for degrees of protection provided by enclosures (IEC 60529)
Tension adjustable back rest upholstery
Yes
Can be used with standard wall-mounted toilets (without extension)
Yes
Intended for children
No
Products for children must comply with the specific demands for safety as stated in certain standards. It is the supplier of the product who has stated that the product is intended for children. The National Board of Social Services holds no responsibility in relation to this assessment.
Powered tilt
Yes
Tilt-in-space dissociated from the height adjustment
Yes
The function of the tilt-in-space is separated from the hydraulic or electrical function of the height adjustment.
Head support
Yes
Battery chargeable separated from the product
Yes
Emergency stopping function
No
Fold-up foot supports
Yes
Height adjustable legrests
Yes
Elevating legrests
Yes
Removable legrests
Yes
Pivoting legrests
Yes
Legrest position may be changed to facililtate hygiene and transfer
Yes
Measures
User weight, max
200
kg
Total width
58.9
cm
Ground clearance
47
cm
Measured from the floor to the lowest point under the seat. Measured without bedpan/collection receptacle.
Width between arm supports
47.3
cm
Smallest distance measured between the inside of the armrests
Seat depth
43
cm
Weight of chair
30
kg
Weight without detachable accessories (detachable without the use of tools)
Toilet opening width
23
cm
Seat height, min
52
cm
Seat height, max
90
cm
Tilt-in-space forward
5
°
Measured from the horizontal position.
Tilt-in-space back
30
°
Measured from the horizontal position.
Wheel diameter
125
mm
Height of push handles/push bar, min.
114.5
cm
Measured from the floor to the upper surface of the grip. According to ISO 17966:2016 it shall be possible to push the chair with the grip 90 cm above the floor.
Height of push handles/push bar, max.
151.5
cm
Measured from the floor to the upper surface of the heigher grip with the chair in the highest position
Test information
No information about tests according to standards ![info](/en/img/i.svg)
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type
EU product safety regulation ![info](/en/img/i.svg)
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device
Product 2 of 2
ErGo-Tilt 4000
HMI-no.
131384
Article-no.
TS-25100
Registration date
15-12-2021
Last updated
19-12-2023
Properties
Possibility to change position of armrest to allow sideways transfer
Ja, opklappelige
Properties
Height adjustable
Elektrisk
Properties
Number of wheels with brake
4
Properties
Ingress protection class for water
IPX9
0-9 (IPX0-IPX9) according to the standard for degrees of protection provided by enclosures (IEC 60529)
Tension adjustable back rest upholstery
Yes
Can be used with standard wall-mounted toilets (without extension)
Yes
Intended for children
No
Products for children must comply with the specific demands for safety as stated in certain standards. It is the supplier of the product who has stated that the product is intended for children. The National Board of Social Services holds no responsibility in relation to this assessment.
Powered tilt
Yes
Tilt-in-space dissociated from the height adjustment
Yes
The function of the tilt-in-space is separated from the hydraulic or electrical function of the height adjustment.
Head support
Yes
Battery chargeable separated from the product
Yes
Emergency stopping function
No
Fold-up foot supports
Yes
Height adjustable legrests
Yes
Elevating legrests
Yes
Removable legrests
Yes
Pivoting legrests
Yes
Legrest position may be changed to facililtate hygiene and transfer
Yes
Measures
User weight, max
200
kg
Total width
58.9
cm
Ground clearance
47
cm
Measured from the floor to the lowest point under the seat. Measured without bedpan/collection receptacle.
Width between arm supports
47.3
cm
Smallest distance measured between the inside of the armrests
Seat depth
43
cm
Weight of chair
30
kg
Weight without detachable accessories (detachable without the use of tools)
Toilet opening width
23
cm
Seat height, min
52
cm
Seat height, max
90
cm
Tilt-in-space forward
5
°
Measured from the horizontal position.
Tilt-in-space back
30
°
Measured from the horizontal position.
Wheel diameter
125
mm
Height of push handles/push bar, min.
114.5
cm
Measured from the floor to the upper surface of the grip. According to ISO 17966:2016 it shall be possible to push the chair with the grip 90 cm above the floor.
Height of push handles/push bar, max.
151.5
cm
Measured from the floor to the upper surface of the heigher grip with the chair in the highest position
Test information ![info](/en/img/i.svg)
Though the product is testet, it might not have passed all requirements in the standard. Besides, some products are only tested according to parts of the standard. Read the test report for detailed information. See also other standards that could be relevant for this product type.
ISO 17966:2016: Assistive products for personal hygiene that support users - Requirements and test methods.
Test lab: Danish Technological Institute. Test date: 11-12-2017
Test report for HMI-no. 131384
Test lab: Danish Technological Institute. Test date: 11-12-2017
EU product safety regulation ![info](/en/img/i.svg)
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device
