Start M2

Start M2

Classification
12 22 03 11 - Manual wheelchairs, sideways foldable, standard measures

Documents
Brochure


The product series contains 6 products.

» Summarize specifications

Product 1 of 6
Start M2, SW 38 cm


HMI-no.
111155
Article-no.
840000021000

Registration date
11-09-2018
Last updated
07-11-2025

Properties
Adjustable seat angle
Yes
Balance point adjustable
Yes
Available with hard base
No
As opposed to sling seat
Back rest angle adjustable
Yes
Height adjustable back rest
Yes
Push handles
Yes
Front-wheel-driven
No
Intended for fastening in a car
Yes
Adjustable seat depth
No
The seat depth in this specific frame can be altered by adjustment or replacement of component(s)

Measures
User weight, max
130
kg
Seat height, min
38
cm
Seat height, max
51
cm
Back rest height, min
40
cm
Back rest height, max
47.5
cm
Total width
58
cm
Total length
95
cm
Weight
14.7
kg
The weight of the wheelchair incl. wheels and leg supports.
Seat width
38
cm
Seat depth, min
40.5
cm
Possibly by adjustment
Seat depth, max
40.5
cm
Longest possible for this frame. Possibly identical to seat depth, min.

Test information
No information about tests according to standards
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

EU product safety regulation
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device

Product 2 of 6
Start M2, SW 40,5 cm


HMI-no.
111169
Article-no.
840000021000

Registration date
11-09-2018
Last updated
07-11-2025

Properties
Adjustable seat angle
Yes
Balance point adjustable
Yes
Available with hard base
No
As opposed to sling seat
Back rest angle adjustable
Yes
Height adjustable back rest
Yes
Push handles
Yes
Front-wheel-driven
No
Intended for fastening in a car
Yes
Adjustable seat depth
No
The seat depth in this specific frame can be altered by adjustment or replacement of component(s)

Measures
User weight, max
130
kg
Seat height, min
38
cm
Seat height, max
51
cm
Back rest height, min
40
cm
Back rest height, max
47.5
cm
Total width
60.5
cm
Total length
95
cm
Weight
14.8
kg
The weight of the wheelchair incl. wheels and leg supports.
Seat width
40.5
cm
Seat depth, min
40.5
cm
Possibly by adjustment
Seat depth, max
40.5
cm
Longest possible for this frame. Possibly identical to seat depth, min.

Test information
No information about tests according to standards
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

EU product safety regulation
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device

Product 3 of 6
Start M2, SW 43 cm


HMI-no.
111172
Article-no.
840000021000

Registration date
11-09-2018
Last updated
07-11-2025

Properties
Adjustable seat angle
Yes
Balance point adjustable
Yes
Available with hard base
No
As opposed to sling seat
Back rest angle adjustable
Yes
Height adjustable back rest
Yes
Push handles
Yes
Front-wheel-driven
No
Intended for fastening in a car
Yes
Adjustable seat depth
No
The seat depth in this specific frame can be altered by adjustment or replacement of component(s)

Measures
User weight, max
130
kg
Seat height, min
38
cm
Seat height, max
51
cm
Back rest height, min
40
cm
Back rest height, max
47.5
cm
Total width
63
cm
Total length
95
cm
Weight
14.9
kg
The weight of the wheelchair incl. wheels and leg supports.
Seat width
43
cm
Seat depth, min
40.5
cm
Possibly by adjustment
Seat depth, max
40.5
cm
Longest possible for this frame. Possibly identical to seat depth, min.

Test information
No information about tests according to standards
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

EU product safety regulation
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device

Product 4 of 6
Start M2, SW 45,5 cm


HMI-no.
111175
Article-no.
840000021000

Registration date
11-09-2018
Last updated
07-11-2025

Properties
Adjustable seat angle
Yes
Balance point adjustable
Yes
Available with hard base
No
As opposed to sling seat
Back rest angle adjustable
Yes
Height adjustable back rest
Yes
Push handles
Yes
Front-wheel-driven
No
Intended for fastening in a car
Yes
Adjustable seat depth
No
The seat depth in this specific frame can be altered by adjustment or replacement of component(s)

Measures
User weight, max
130
kg
Seat height, min
38
cm
Seat height, max
51
cm
Back rest height, min
40
cm
Back rest height, max
47.5
cm
Total width
65.5
cm
Total length
95
cm
Weight
15
kg
The weight of the wheelchair incl. wheels and leg supports.
Seat width
45.5
cm
Seat depth, min
40.5
cm
Possibly by adjustment
Seat depth, max
40.5
cm
Longest possible for this frame. Possibly identical to seat depth, min.

Test information
No information about tests according to standards
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

EU product safety regulation
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device

Product 5 of 6
Start M2, SW 48 cm


HMI-no.
111178
Article-no.
840000021000

Registration date
11-09-2018
Last updated
07-11-2025

Properties
Adjustable seat angle
Yes
Balance point adjustable
Yes
Available with hard base
No
As opposed to sling seat
Back rest angle adjustable
Yes
Height adjustable back rest
Yes
Push handles
Yes
Front-wheel-driven
No
Intended for fastening in a car
Yes
Adjustable seat depth
No
The seat depth in this specific frame can be altered by adjustment or replacement of component(s)

Measures
User weight, max
130
kg
Seat height, min
38
cm
Seat height, max
51
cm
Back rest height, min
40
cm
Back rest height, max
47.5
cm
Total width
68
cm
Total length
95
cm
Weight
15.1
kg
The weight of the wheelchair incl. wheels and leg supports.
Seat width
48
cm
Seat depth, min
40.5
cm
Possibly by adjustment
Seat depth, max
40.5
cm
Longest possible for this frame. Possibly identical to seat depth, min.

Test information
No information about tests according to standards
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

EU product safety regulation
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device

Product 6 of 6
Start M2, SW 50,5 cm


HMI-no.
111181
Article-no.
840000021000

Registration date
11-09-2018
Last updated
07-11-2025

Properties
Adjustable seat angle
Yes
Balance point adjustable
Yes
Available with hard base
No
As opposed to sling seat
Back rest angle adjustable
Yes
Height adjustable back rest
Yes
Push handles
Yes
Front-wheel-driven
No
Intended for fastening in a car
Yes
Adjustable seat depth
No
The seat depth in this specific frame can be altered by adjustment or replacement of component(s)

Measures
User weight, max
130
kg
Seat height, min
38
cm
Seat height, max
51
cm
Back rest height, min
40
cm
Back rest height, max
47.5
cm
Total width
70.5
cm
Total length
95
cm
Weight
15.2
kg
The weight of the wheelchair incl. wheels and leg supports.
Seat width
50.5
cm
Seat depth, min
40.5
cm
Possibly by adjustment
Seat depth, max
40.5
cm
Longest possible for this frame. Possibly identical to seat depth, min.

Test information
No information about tests according to standards
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

EU product safety regulation
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device
