Arjo, Citadel hospitalbed



Citadel er et integreret system til stærkt plejekrævende patienter. Med CPR funktion og mikroklimakontrol (NAT). Automatisk trykkompensering i sædesektionen finder sted, når sengens hovedende justeres. Derudover forhindres automatisk vending, når sengens hovedende overstiger 30 grader, eller hvis en eller flere af sengehestene er slået ned.

Classification
18 12 10 34 - Lateral tilt beds

Documents
User manual


The product series contains 1 product.

Product 1 of 1
Arjo, Citadel hospitalbed


HMI-no.
113638
Article-no.
CXX22C4T4ALMD0, MATT0018, MATT0002

Registration date
02-01-2019
Last updated
11-09-2025

Properties
Number of sections of mattress support platform, longitudinal
1

Properties
Number of sections of mattress support platform, transversely
1
1, 2, 3, or 4 sectioned mattress support platform, e.g. back rest, seat, upper leg and lower leg sections.

Properties
Adjustment of the height of mattress support platform
Elektrisk
Bed extension
Yes
Bed extension, follows the movements of the mattress support platform
No
Intended for use in hospitals
Yes
Intended for use in nursing institutions
No
Intended for long-term care in a medical area where medical supervision is required and monitoring is provided if necessary, e.g. nursing homes and rehabilitation and geriatic facilities.
Intended for use in a domestic area
No
Machine washable
No
Machine washable at least 50 times according to EN 50637:2017 and EN 60601-2-52:2010/A1:2015.
Central braking system
Yes
Back rest section, electrical adjustment
Yes
Leg section, electrical adjustment
No
Upper leg section, electrical adjustment
Yes
Separate adjustment of back rest
Yes
Indicates whether the back rest can be adjusted independently of other parts of the mattress support platform
Combined adjustment of mattress support platform
Yes
Indicates whether back rest and knee bending can be adjusted with one control button
Lateral tilt function, electrically operated
No
Stand-up function, manually operated
No
The mattress support platform can be adjustet manually in a manner where the person is raised to a standing position in the bed.
Stand-up function, electrically operated
No
The mattress support platform can be electrically adjustet in a manner where the person is raised to a standing position in the bed.
Removable bed-rails
Yes
Removable self-lifting rail
No
Removable foot board
No
Removable head board
Yes
Adjustable head support section
No
Trendelenburg, manual operation
No
Trendelenburg, electrical operation
Yes
Anti-trendelenburg, manual operation
No
Anti-trendelenburg, electrical operation
Yes

Measures
Outside measure length
230
cm
Measured without any bed extension
Outside measure width
103
cm
Measured including non-detachable accessories
Mattress size, length
202
cm
Mattress size, width
88
cm
Load, max
270
kg
Maximum external load on the product that is permitted in normal use
User weight, max
227
kg
Weight of heaviest main part
200
kg
Weight of heaviest part when disassembled without the use of tools.
Ingress protection class for water
4
IP
0-9 (IPX0-IPX9) according to the standard for degrees of protection provided by enclosures (IEC 60529)
Mattress support platform, height above floor, min
34
cm
Measured without mattress
Mattress support platform, height above floor, max
78
cm
Measured without mattress
Under bed clearance
14
cm
Minimum under bed clearance in the 100 cm middle area measured from the floor with the mattress support platform 40-80 cm above the floor.
Wheel diameter
12.5
cm

Test information
No information about tests according to standards
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

EU product safety regulation
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device
