Electric wheelchairs




Classification
12 23 06 08 - Powered wheelchairs, powered steering, class B (for indoor and outdoor use)

Documents
User manual
QuickGuide
Service manual


The product series contains 3 products.
The product series also includes 6 discontinued products. Include discontinued products.

» Summarize specifications

Product 1 of 3
MC 1124


HMI-no.
139127
Article-no.
2400-1293

Registration date
13-11-2023
Last updated
05-11-2026

Properties
Programmable
Yes
Elevating seat
Yes
Powered recline
Yes
Powered tilt
Yes
Powered legrests
Yes
Optional motorized attendant control
Yes
Suspension
Yes
Front-wheel-driven
No
Mid-wheel-driven
Yes
Rear-wheel-driven
No
Can be used as seat in a car
Yes

Measures
User weight, max
150
kg
External width
61
cm
Measured where widest
External length
122
cm
Maximum external length with the seat in an upright position. Measured without leg supports
Weight
165
kg
Speed, max
10
km/t
Driving distance range, fully charged
45
km
The theoretical driving distance range as calculated through laboratory testing.
Seat height, min
51
cm
The vertical distance between the floor and the seat surface measured at the front edge of the seat. Measured with the seat in the lowest position.
Seat height, max
81
cm
The vertical distance between the floor and the seat surface measured at the front edge of the seat. Measured with the seat in the highest position.
Back rest recline, max
50
°
Recline of back rest from an upright position.
Tilt-in-space forward
5
°
Measured from the horizontal position.
Tilt-in-space back
45
°
Measured from the horizontal position.
Ground clearance
7
cm
Slope, max
6
°
Climbs obstacles of max
7
cm

Test information
Though the product is testet, it might not have passed all requirements in the standard. Besides, some products are only tested according to parts of the standard. Read the test report for detailed information. See also other standards that could be relevant for this product type.
ISO 7176-19:2022: Wheelchairs - Part 19: Wheelchairs for use as seats in motor vehicles.
Test lab: Dahl Engineering - Research and Testing Laboratory. Test date: 23-05-2023 Test report for HMI-no. 139127

EN 12184:2022: Electrically powered wheelchairs, scooters and their chargers - Requirements and test methods.
Test lab: TÜV Rheinland Nederland B.V.. Test date: 17-05-2018 Test report for HMI-no. 139127

EU product safety regulation
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device
EU declaration of conformity for HMI-no. 139127

Product 2 of 3
MC 1124


HMI-no.
139241
Article-no.
2400-1295

Registration date
27-11-2023
Last updated
05-11-2026

Properties
Programmable
Yes
Elevating seat
Yes
Powered recline
Yes
Powered tilt
Yes
Powered legrests
No
Optional motorized attendant control
Yes
Suspension
Yes
Front-wheel-driven
No
Mid-wheel-driven
Yes
Rear-wheel-driven
No
Can be used as seat in a car
Yes

Measures
User weight, max
150
kg
External width
61
cm
Measured where widest
External length
122
cm
Maximum external length with the seat in an upright position. Measured without leg supports
Weight
165
kg
Speed, max
10
km/t
Driving distance range, fully charged
45
km
The theoretical driving distance range as calculated through laboratory testing.
Seat height, min
51
cm
The vertical distance between the floor and the seat surface measured at the front edge of the seat. Measured with the seat in the lowest position.
Seat height, max
81
cm
The vertical distance between the floor and the seat surface measured at the front edge of the seat. Measured with the seat in the highest position.
Back rest recline, max
50
°
Recline of back rest from an upright position.
Tilt-in-space forward
5
°
Measured from the horizontal position.
Tilt-in-space back
45
°
Measured from the horizontal position.
Ground clearance
7
cm
Slope, max
6
°
Climbs obstacles of max
7
cm

Test information
Though the product is testet, it might not have passed all requirements in the standard. Besides, some products are only tested according to parts of the standard. Read the test report for detailed information. See also other standards that could be relevant for this product type.
ISO 7176-19:2022: Wheelchairs - Part 19: Wheelchairs for use as seats in motor vehicles.
Test lab: Dahl Engineering - Research and Testing Laboratory. Test date: 23-05-2023 Test report for HMI-no. 139241

EN 12184:2022: Electrically powered wheelchairs, scooters and their chargers - Requirements and test methods.
Test lab: TÜV Rheinland Nederland B.V.. Test date: 17-05-2018 Test report for HMI-no. 139241

EU product safety regulation
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device
EU declaration of conformity for HMI-no. 139241

Product 3 of 3
MC1124


HMI-no.
139239
Article-no.
2400-1274

Registration date
27-11-2023
Last updated
21-10-2026

Properties
Programmable
Yes
Elevating seat
Yes
Powered recline
Yes
Powered tilt
Yes
Powered legrests
Yes
Optional motorized attendant control
Yes
Suspension
Yes
Front-wheel-driven
No
Mid-wheel-driven
Yes
Rear-wheel-driven
No
Can be used as seat in a car
Yes

Measures
User weight, max
150
kg
External width
61
cm
Measured where widest
External length
122
cm
Maximum external length with the seat in an upright position. Measured without leg supports
Weight
165
kg
Speed, max
10
km/t
Driving distance range, fully charged
45
km
The theoretical driving distance range as calculated through laboratory testing.
Tilt-in-space forward
5
°
Measured from the horizontal position.
Tilt-in-space back
45
°
Measured from the horizontal position.
Ground clearance
7
cm
Slope, max
6
°
Climbs obstacles of max
7
cm

Test information
No information about tests according to standards
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

EU product safety regulation
No information about CE-marking
The supplier has not provided any information about CE-marking of the product. Explain CE-marking
