TSN HS-520




Classification
12 23 03 06 - Powered wheelchair, manual steering, class B (for indoor and outdoor use)

Documents
Brochure
Accessories catalogue


The product series contains 1 product.

Product 1 of 1
TSN HS-520


HMI-no.
120293
Article-no.
TSN/HS-520

Registration date
25-11-2019
Last updated
21-11-2023

Properties
Number of wheels
4
Intended for children
No
info
Products for children must comply with the specific demands for safety as stated in certain standards. It is the supplier of the product who has stated that the product is intended for children. The National Board of Social Services holds no responsibility in relation to this assessment.
Programmable
Yes
Suspension
Yes
Can be used as seat in a car
No
Can be disassembled without tools
Yes
With cubicle
No
Intended/suitable for one-hand operation
Yes
info
All steering and control functions must be operationable on the same side and with one hand.

Measures
User weight, max
135
kg
Width
64
cm
info
Maximum external width.
Length
120
cm
info
Maximum external length without extra accessories.
Weight
94
kg
Seat height, min
60
cm
info
The vertical distance between the foot rest and the seat surface measured at the front edge of the seat. Measured with the seat in the lowest position.
Seat height, max
67
cm
info
The vertical distance between the foot rest and the seat surface measured at the front edge of the seat. Measured with the seat in the highest position.
Speed, max
12
km/t
Driving distance range, fully charged
40
km
info
The theoretical driving distance range as calculated through laboratory testing.
Ground clearance
8
cm
Turning diameter
140
cm
Slope, max
10
°
Climbs obstacles of max
60
cm
Weight of heaviest main part
30
kg

Test information
No information about tests according to standards info
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

EU product safety regulation
No information about CE-marking info
The supplier has not provided any information about CE-marking of the product. Explain CE-marking
