TSN HS-828




Classification
12 23 03 07 - Powered wheelchair, manual steering, class C (primarily for outdoor use)

Documents
Brochure
Accessories catalogue


The product series contains 1 product.

Product 1 of 1
TSN HS-828


HMI-no.
120296
Article-no.
TSN/HS-828 50A

Registration date
25-11-2019
Last updated
22-09-2025

Properties
Number of wheels
4
Programmable
Yes
Suspension
Yes
Can be used as seat in a car
No
Can be disassembled without tools
Yes
With cubicle
No

Measures
User weight, max
180
kg
Width
68
cm
Maximum external width.
Length
140
cm
Maximum external length without extra accessories.
Weight
124
kg
Seat height, min
60
cm
The vertical distance between the foot rest and the seat surface measured at the front edge of the seat. Measured with the seat in the lowest position.
Seat height, max
68
cm
The vertical distance between the foot rest and the seat surface measured at the front edge of the seat. Measured with the seat in the highest position.
Speed, max
15
km/t
Driving distance range, fully charged
40
km
The theoretical driving distance range as calculated through laboratory testing.
Ground clearance
9
cm
Slope, max
12
°
Climbs obstacles of max
12
cm
Weight of heaviest main part
30
kg

Test information
No information about tests according to standards
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type

EU product safety regulation
No information about CE-marking
The supplier has not provided any information about CE-marking of the product. Explain CE-marking
