ICON 60




Classification
12 22 03 13 - Manual wheelchairs with rigid frame, standard measures

Documents
Brochure
User manual


The product series contains 7 products.

» Summarize specifications

Product 1 of 7
ICON 60, SB36


HMI-no.
134702

Registration date
21-12-2022
Last updated
22-10-2025

Properties
Number of wheels
4
Adjustable seat angle
Yes
Balance point adjustable
Yes
Available with hard base
No
As opposed to sling seat
Back rest angle adjustable
Yes
Height adjustable back rest
Yes
Push handles
Yes
Front-wheel-driven
No
Intended for fastening in a car
No

Measures
User weight, max
120
kg
Seat height, min
36
cm
Seat height, max
52.5
cm
Back rest height, min
25
cm
Back rest height, max
48
cm
Total width
50
cm
Total length
80
cm
Weight
9.3
kg
The weight of the wheelchair incl. wheels and leg supports.
Seat width
36
cm
Seat depth
32
cm

Test information
Though the product is testet, it might not have passed all requirements in the standard. Besides, some products are only tested according to parts of the standard. Read the test report for detailed information. See also other standards that could be relevant for this product type.
EN 12183:2014: Manual wheelchairs - Requirements and test methods.
Test lab: Centre for Testing and Certification - Mech Test. Test date: 27-12-2019 Test report for HMI-no. 134702

EN 12182:2012: Assistive products for persons with disability - General requirements and test methods.
Test lab: Centre for Testing and Certification - Mech Test. Test date: 27-12-2021 Test report for HMI-no. 134702

EU product safety regulation
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device
EU declaration of conformity for HMI-no. 134702

Other specifications
Available in black, white, silver, gold, red and blue


Product 2 of 7
ICON 60, SB38


HMI-no.
134703

Registration date
21-12-2022
Last updated
22-10-2025

Properties
Number of wheels
4
Adjustable seat angle
Yes
Balance point adjustable
Yes
Available with hard base
No
As opposed to sling seat
Back rest angle adjustable
Yes
Height adjustable back rest
Yes
Push handles
Yes
Front-wheel-driven
No
Intended for fastening in a car
No

Measures
User weight, max
120
kg
Seat height, min
36
cm
Seat height, max
52.5
cm
Back rest height, min
25
cm
Back rest height, max
48
cm
Total width
52
cm
Total length
80
cm
Weight
9.4
kg
The weight of the wheelchair incl. wheels and leg supports.
Seat width
38
cm
Seat depth
32
cm

Test information
Though the product is testet, it might not have passed all requirements in the standard. Besides, some products are only tested according to parts of the standard. Read the test report for detailed information. See also other standards that could be relevant for this product type.
EN 12183:2014: Manual wheelchairs - Requirements and test methods.
Test lab: Centre for Testing and Certification - Mech Test. Test date: 27-12-2019 Test report for HMI-no. 134703

EN 12182:2012: Assistive products for persons with disability - General requirements and test methods.
Test lab: Centre for Testing and Certification - Mech Test. Test date: 27-12-2021 Test report for HMI-no. 134703

EU product safety regulation
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device
EU declaration of conformity for HMI-no. 134703

Product 3 of 7
ICON 60, SB40


HMI-no.
134704

Registration date
21-12-2022
Last updated
22-10-2025

Properties
Number of wheels
4
Adjustable seat angle
Yes
Balance point adjustable
Yes
Available with hard base
No
As opposed to sling seat
Back rest angle adjustable
Yes
Height adjustable back rest
Yes
Push handles
Yes
Front-wheel-driven
No
Intended for fastening in a car
No

Measures
User weight, max
120
kg
Seat height, min
36
cm
Seat height, max
52.5
cm
Back rest height, min
25
cm
Back rest height, max
48
cm
Total width
54
cm
Total length
80
cm
Weight
9.5
kg
The weight of the wheelchair incl. wheels and leg supports.
Seat width
40
cm
Seat depth
32
cm

Test information
Though the product is testet, it might not have passed all requirements in the standard. Besides, some products are only tested according to parts of the standard. Read the test report for detailed information. See also other standards that could be relevant for this product type.
EN 12183:2014: Manual wheelchairs - Requirements and test methods.
Test lab: Centre for Testing and Certification Mesh-Test 05-077 Warszawa We. Test date: 27-12-2019 Test report for HMI-no. 134704

EN 12182:2012: Assistive products for persons with disability - General requirements and test methods.
Test lab: Centre for Testing and Certification - Mech Test. Test date: 27-12-2019 Test report for HMI-no. 134704

EU product safety regulation
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device
EU declaration of conformity for HMI-no. 134704

Product 4 of 7
ICON 60, SB42


HMI-no.
134705

Registration date
21-12-2022
Last updated
22-10-2025

Properties
Number of wheels
4
Adjustable seat angle
Yes
Balance point adjustable
Yes
Available with hard base
No
As opposed to sling seat
Back rest angle adjustable
Yes
Height adjustable back rest
Yes
Push handles
Yes
Front-wheel-driven
No
Intended for fastening in a car
No

Measures
User weight, max
120
kg
Seat height, min
36
cm
Seat height, max
52.5
cm
Back rest height, min
25
cm
Back rest height, max
48
cm
Total width
56
cm
Total length
80
cm
Weight
9.6
kg
The weight of the wheelchair incl. wheels and leg supports.
Seat width
42
cm
Seat depth
32
cm

Test information
Though the product is testet, it might not have passed all requirements in the standard. Besides, some products are only tested according to parts of the standard. Read the test report for detailed information. See also other standards that could be relevant for this product type.
EN 12183:2014: Manual wheelchairs - Requirements and test methods.
Test lab: Centre for Testing and Certification Mesh-Test 05-077 Warszawa We. Test date: 27-12-2019 Test report for HMI-no. 134705

EN 12182:2012: Assistive products for persons with disability - General requirements and test methods.
Test lab: Centre for Testing and Certification - Mech Test. Test date: 27-12-2019 Test report for HMI-no. 134705

EU product safety regulation
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device
EU declaration of conformity for HMI-no. 134705

Product 5 of 7
ICON 60, SB44


HMI-no.
134706

Registration date
21-12-2022
Last updated
22-10-2025

Properties
Number of wheels
4
Adjustable seat angle
Yes
Balance point adjustable
Yes
Available with hard base
No
As opposed to sling seat
Back rest angle adjustable
Yes
Height adjustable back rest
Yes
Push handles
Yes
Front-wheel-driven
No
Intended for fastening in a car
No

Measures
User weight, max
120
kg
Seat height, min
36
cm
Seat height, max
52.5
cm
Back rest height, min
25
cm
Back rest height, max
48
cm
Total width
58
cm
Total length
80
cm
Weight
9.7
kg
The weight of the wheelchair incl. wheels and leg supports.
Seat width
44
cm
Seat depth
32
cm

Test information
Though the product is testet, it might not have passed all requirements in the standard. Besides, some products are only tested according to parts of the standard. Read the test report for detailed information. See also other standards that could be relevant for this product type.
EN 12183:2014: Manual wheelchairs - Requirements and test methods.
Test lab: Centre for Testing and Certification - Mech Test. Test date: 13-12-2021 Test report for HMI-no. 134706

EN 12182:2012: Assistive products for persons with disability - General requirements and test methods.
Test lab: Centre for Testing and Certification - Mech Test. Test date: 13-12-2021 Test report for HMI-no. 134706

EU product safety regulation
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device
EU declaration of conformity for HMI-no. 134706

Product 6 of 7
ICON 60, SB46


HMI-no.
134707

Registration date
21-12-2022
Last updated
22-10-2025

Properties
Number of wheels
4
Adjustable seat angle
Yes
Balance point adjustable
Yes
Available with hard base
No
As opposed to sling seat
Back rest angle adjustable
Yes
Height adjustable back rest
Yes
Push handles
Yes
Front-wheel-driven
No
Intended for fastening in a car
No

Measures
User weight, max
120
kg
Seat height, min
36
cm
Seat height, max
52.5
cm
Back rest height, min
25
cm
Back rest height, max
48
cm
Total width
60
cm
Total length
80
cm
Weight
9.8
kg
The weight of the wheelchair incl. wheels and leg supports.
Seat width
46
cm
Seat depth
32
cm

Test information
Though the product is testet, it might not have passed all requirements in the standard. Besides, some products are only tested according to parts of the standard. Read the test report for detailed information. See also other standards that could be relevant for this product type.
EN 12183:2014: Manual wheelchairs - Requirements and test methods.
Test lab: Centre for Testing and Certification - Mech Test. Test date: 13-12-2021 Test report for HMI-no. 134707

EN 12182:2012: Assistive products for persons with disability - General requirements and test methods.
Test lab: Centre for Testing and Certification - Mech Test. Test date: 13-12-2021 Test report for HMI-no. 134707

EU product safety regulation
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device
EU declaration of conformity for HMI-no. 134707

Product 7 of 7
ICON 60, SB48


HMI-no.
134708

Registration date
21-12-2022
Last updated
22-10-2025

Properties
Number of wheels
4
Adjustable seat angle
Yes
Balance point adjustable
Yes
Available with hard base
No
As opposed to sling seat
Back rest angle adjustable
Yes
Height adjustable back rest
Yes
Push handles
Yes
Front-wheel-driven
No
Intended for fastening in a car
No

Measures
User weight, max
120
kg
Seat height, min
36
cm
Seat height, max
52.5
cm
Back rest height, min
25
cm
Back rest height, max
48
cm
Total width
62
cm
Total length
80
cm
Weight
9.9
kg
The weight of the wheelchair incl. wheels and leg supports.
Seat width
48
cm
Seat depth
32
cm

Test information
Though the product is testet, it might not have passed all requirements in the standard. Besides, some products are only tested according to parts of the standard. Read the test report for detailed information. See also other standards that could be relevant for this product type.
EN 12183:2014: Manual wheelchairs - Requirements and test methods.
Test lab: Centre for Testing and Certification - Mech Test. Test date: 13-12-2021 Test report for HMI-no. 134708

EN 12182:2012: Assistive products for persons with disability - General requirements and test methods.
Test lab: Centre for Testing and Certification - Mech Test. Test date: 13-12-2021 Test report for HMI-no. 134708

EU product safety regulation
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device
EU declaration of conformity for HMI-no. 134708
