Bade/toiletstol M2 El-tip
Classification
09 12 03 11 - Commode shower chairs with wheels, tilt and electrical functions
The product series contains 2 products.
The product series also includes 2 discontinued products. Include discontinued products.
Product 1 of 2
Bade/toiletstol M2 El-tip m. intimsæde - BOXED
HMI-no.
100133
Article-no.
310211-B
Registration date
21-01-2016
Last updated
18-11-2024
Properties
Possibility to change position of armrest to allow sideways transfer
Ja, opklappelige
Properties
Height adjustable
Manuelt
Properties
Number of wheels with brake
4
Properties
Ingress protection class for water
IPX6
0-9 (IPX0-IPX9) according to the standard for degrees of protection provided by enclosures (IEC 60529)
Tension adjustable back rest upholstery
Yes
Can be used with standard wall-mounted toilets (without extension)
Yes
Intended for children
No
Products for children must comply with the specific demands for safety as stated in certain standards. It is the supplier of the product who has stated that the product is intended for children. The National Board of Social Services holds no responsibility in relation to this assessment.
Powered tilt
Yes
Tilt-in-space dissociated from the height adjustment
Yes
The function of the tilt-in-space is separated from the hydraulic or electrical function of the height adjustment.
Head support
Yes
Battery chargeable separated from the product
No
Emergency stopping function
No
Fold-up foot supports
Yes
Height adjustable legrests
Yes
Elevating legrests
Yes
Removable legrests
Yes
Pivoting legrests
Yes
Legrest position may be changed to facililtate hygiene and transfer
No
Measures
User weight, max
150
kg
Total width
59
cm
Ground clearance
46.5
cm
Measured from the floor to the lowest point under the seat. Measured without bedpan/collection receptacle.
Width between arm supports
46.5
cm
Smallest distance measured between the inside of the armrests
Seat depth
44
cm
Toilet opening width
22
cm
Seat height, min
55.5
cm
Seat height, max
61.5
cm
Tilt-in-space forward
7
°
Measured from the horizontal position.
Tilt-in-space back
37
°
Measured from the horizontal position.
Wheel diameter
125
mm
Height of push handles/push bar, min.
100
cm
Measured from the floor to the upper surface of the grip. According to ISO 17966:2016 it shall be possible to push the chair with the grip 90 cm above the floor.
Height of push handles/push bar, max.
106
cm
Measured from the floor to the upper surface of the heigher grip with the chair in the highest position
Test information
Though the product is testet, it might not have passed all requirements in the standard. Besides, some products are only tested according to parts of the standard. Read the test report for detailed information. See also other standards that could be relevant for this product type.
: Tested according to other national or international standard.
Test lab: Test Laboratory ELTEST. Test date: 20-01-2022
Test report for HMI-no. 100133
Test lab: Test Laboratory ELTEST. Test date: 20-01-2022
Test report for HMI-no. 100133EU product safety regulation
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device
Product 2 of 2
Bade/toiletstol M2 El-tip m. standardsæde - BOXED
HMI-no.
100134
Article-no.
310210-B
Registration date
21-01-2016
Last updated
18-11-2024
Properties
Possibility to change position of armrest to allow sideways transfer
Ja, opklappelige
Properties
Height adjustable
Manuelt
Properties
Number of wheels with brake
4
Properties
Ingress protection class for water
IPX6
0-9 (IPX0-IPX9) according to the standard for degrees of protection provided by enclosures (IEC 60529)
Tension adjustable back rest upholstery
Yes
Can be used with standard wall-mounted toilets (without extension)
Yes
Intended for children
No
Products for children must comply with the specific demands for safety as stated in certain standards. It is the supplier of the product who has stated that the product is intended for children. The National Board of Social Services holds no responsibility in relation to this assessment.
Powered tilt
Yes
Tilt-in-space dissociated from the height adjustment
Yes
The function of the tilt-in-space is separated from the hydraulic or electrical function of the height adjustment.
Head support
Yes
Battery chargeable separated from the product
No
Emergency stopping function
No
Fold-up foot supports
Yes
Height adjustable legrests
Yes
Elevating legrests
Yes
Removable legrests
Yes
Pivoting legrests
Yes
Legrest position may be changed to facililtate hygiene and transfer
No
Measures
User weight, max
150
kg
Total width
59
cm
Ground clearance
46.5
cm
Measured from the floor to the lowest point under the seat. Measured without bedpan/collection receptacle.
Width between arm supports
46.5
cm
Smallest distance measured between the inside of the armrests
Seat depth
44
cm
Toilet opening width
22
cm
Seat height, min
55.5
cm
Seat height, max
61.5
cm
Tilt-in-space forward
7
°
Measured from the horizontal position.
Tilt-in-space back
37
°
Measured from the horizontal position.
Wheel diameter
125
mm
Height of push handles/push bar, min.
100
cm
Measured from the floor to the upper surface of the grip. According to ISO 17966:2016 it shall be possible to push the chair with the grip 90 cm above the floor.
Height of push handles/push bar, max.
106
cm
Measured from the floor to the upper surface of the heigher grip with the chair in the highest position
Test information
Though the product is testet, it might not have passed all requirements in the standard. Besides, some products are only tested according to parts of the standard. Read the test report for detailed information. See also other standards that could be relevant for this product type.
: Tested according to other national or international standard.
Test lab: Test Laboratory ELTEST. Test date: 20-01-2022Test report for HMI-no. 100134
Test lab: Test Laboratory ELTEST. Test date: 20-01-2022
Test report for HMI-no. 100134EU product safety regulation
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device
