ErGo OpTi



Multifunctional toilet and bath chair for an optimal working environment when dressing and undressing

Classification
09 12 03 11 - Commode shower chairs with wheels, tilt and electrical functions

Documents
Brochure
User manual
QuickGuide
Accessories catalogue
Spare part catalogue

Video
Play video


The product series contains 1 product.

Product 1 of 1
Ergo-opti


HMI-no.
134843
Article-no.
TS-37500

Registration date
02-01-2023
Last updated
11-09-2025

Properties
Height adjustable
Elektrisk
Tension adjustable back rest upholstery
Yes
Can be used with standard wall-mounted toilets (without extension)
Yes
Possibility to change position of armrest to allow sideways transfer
Yes
Powered tilt
Yes
Tilt-in-space dissociated from the height adjustment
Yes
The function of the tilt-in-space is separated from the hydraulic or electrical function of the height adjustment.
Head support
Yes
Battery chargeable separated from the product
Yes
Emergency stopping function
No
Fold-up foot supports
Yes
Height adjustable legrests
Yes
Elevating legrests
Yes
Legrest position may be changed to facililtate hygiene and transfer
Yes

Measures
User weight, max
200
kg
Total width
58
cm
Ground clearance
80
cm
Measured from the floor to the lowest point under the seat. Measured without bedpan/collection receptacle.
Width between arm supports
48
cm
Smallest distance measured between the inside of the arm supports. If the arm supports are adjustable, this is measured with the arm supports in the widest position.
Seat depth
42
cm
If the seat depth is adjustable, this is the maximum seat depth
Wheel diameter
125
mm
Number of wheels with brake
4
Seat height, min
51
cm
Seat height, max
95
cm
Tilt-in-space forward
5
°
Measured from the horizontal position.
Tilt-in-space back
90
°
Measured from the horizontal position.
Height of push handles/push bar, min.
110
cm
Measured from the floor to the upper surface of the grip. According to ISO 17966:2016 it shall be possible to push the chair with the grip 90 cm above the floor.
Height of push handles/push bar, max.
147
cm
Measured from the floor to the upper surface of the heigher grip with the chair in the highest position
Ingress protection class for water
9
IP
0-9 (IPX0-IPX9) according to the standard for degrees of protection provided by enclosures (IEC 60529)

Test information
Though the product is testet, it might not have passed all requirements in the standard. Besides, some products are only tested according to parts of the standard. Read the test report for detailed information. See also other standards that could be relevant for this product type.
ISO 17966:2016: Assistive products for personal hygiene that support users - Requirements and test methods.
Test lab: Danish Technological Institute. Test date: 11-12-2017 Test report for HMI-no. 134843

: Tested according to other national or international standard.
Test lab: Force. Test date: 05-07-2018 Test report for HMI-no. 134843

EU product safety regulation
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device
