Arjo, Sara Flex standing and raising aid
Sara Flex enables a single caregiver to assist a patient or resident from a seated to a standing position, in one movement. Promotes comfort and security throughout and at the completion of the sit-to-stand movement. Designed with ease of use for the single caregiver in mind, no adjustments required. DSDC Product Accreditation Rating Class 1B
Classification
12 36 04 01 - Mobile hoists for transferring a person in standing position
BrochureVideo
Play videoThe product series contains 2 products.
Product 1 of 2
Sara Flex standing and raising aid
HMI-no.
108985
Article-no.
HEB0000-34
Registration date
23-03-2018
Last updated
19-12-2023
Properties
Ingress protection class for water
IPX7
0-9 (IPX0-IPX9) according to the standard for degrees of protection provided by enclosures (IEC 60529)
Electrical lifting mechanism
Yes
Electrical width adjustment of base
Yes
Parallel width adjustment of base
No
Leg support adjustable in height
Yes
Leg support horizontal adjustable
Yes
Leg support adjustable without tools
Yes
Split leg support
No
Foldable
No
Can be disassembled without tools
No
Integrated battery charger
No
Emergency lowering function
Yes
Unit for use with sling(s) available
Yes
Measures
User weight, max
200
kg
Lifting height, max
151.8
cm
Internal width of base, max
102.9
cm
External width of base in the most narrow position
66
cm
Height of base at front
11
cm
Turning diameter
120.8
cm
Diameter of the narrowest circle encompassing the extreme points of the hoist, when it is turned 360 degrees without beeing reversed.
Weight of heaviest main part
14.6
kg
Maintenance frequency
12
måneder
Test information
No information about tests according to standards
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type
EU product safety regulation
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device
Other specifications
Sara Flex´s flexible silicone legsupport enables the horizontal forward movement of the knees while standing up. This is described in the study: An evaluation of sit to stand devices for use in rehabilitation. Loughborough University, UK. Please contact Arjo
Product 2 of 2
Sara Flex standing and raising aid with scale
HMI-no.
109930
Article-no.
HEB2000-34
Registration date
12-06-2018
Last updated
19-12-2023
Properties
Ingress protection class for water
IPX7
0-9 (IPX0-IPX9) according to the standard for degrees of protection provided by enclosures (IEC 60529)
Electrical lifting mechanism
Yes
Electrical width adjustment of base
No
Parallel width adjustment of base
No
Leg support adjustable in height
Yes
Leg support horizontal adjustable
Yes
Leg support adjustable without tools
Yes
Split leg support
No
Foldable
No
Can be disassembled without tools
No
Integrated battery charger
No
Emergency lowering function
Yes
Unit for use with sling(s) available
Yes
Measures
User weight, max
200
kg
Lifting height, max
151.8
cm
Internal width of base, max
102.9
cm
External width of base in the most narrow position
66
cm
Height of base at front
11
cm
Turning diameter
120.8
cm
Diameter of the narrowest circle encompassing the extreme points of the hoist, when it is turned 360 degrees without beeing reversed.
Weight of heaviest main part
14.6
kg
Maintenance frequency
12
måneder
Test information
No information about tests according to standards
The supplier has not provided documentation, that this product is testet according to a relevant standard. See examples of relevant standards for this product type
EU product safety regulation
The supplier has provided the following information about CE-marking of the product. Explain CE-marking
CE marked as medical device
Other specifications
Sara Flex standing and raising aid with scale. Weighing capacity: 200 kg.
Sara Flex´s flexible silicone legsupport enables the horizontal forward movement of the knees while standing up. This is described in the study: An evaluation of sit to stand devices for use in rehabilitation. Loughborough University, UK. Please contact Arjo
Sara Flex´s flexible silicone legsupport enables the horizontal forward movement of the knees while standing up. This is described in the study: An evaluation of sit to stand devices for use in rehabilitation. Loughborough University, UK. Please contact Arjo
